Creative Equipment

Circus 0-37215-500

Classic

City

Aloha

Beach

Coral

Ice Palace

Jungle

Mermaid

Nature

Ocean

Pirate

Safari

Sky

Sun

Sunny Day

Sweden

Technical specifications

Lifting device ? Appropriate hoisting equipment is necessary for assembling the playground equipment.

Total length ? The measurement indicating the length of the playground equipment.

1,75 m

Total width ? The measurement indicating the width of the playground equipment.

1,50 m

Total height ? The measurement indicating the height of the playground equipment.

1,50 m

Minimum space length ? The minimum required length for the space where the playground equipment will be placed.

4,75 m

Minimum space width ? The minimum required width for the space where the playground equipment will be placed.

4,75 m

Minimum space height ? The minimum required height for the space where the playground equipment will be placed.

1,50 m

Number of installers ? The number of qualified individuals required for product assembly.

2 Pers.

Assembly time ? The time required by qualified individuals to assemble the product.

2 h

Heaviest single piece ? The weight of the heaviest component of the product. This information is crucial for transportation and assembly.

40,00 kg

(Total) Weight ? The total weight of the product. This information is essential for transportation and assembly.

295,00 kg

Free height of fall ? The maximum free fall height of the product, from which the required impact-absorbing surfaces, impact area size, and fall protection requirements can be derived according to (DIN) EN 1176-1:2017.

No specification

Platform heights

Foundations

6 pcs.

0,40 x 0,40 x 0,40 m
Volume: 0,06 m3

Age group ? The specific age group for which the product was developed.

2+
Number of users ? The number of individuals who can use the product simultaneously.

12
Area of use ? The different environments or situations in which the product can be used.

public playgrounds
Activities ? The various tasks or actions that can be performed with the product.

manual activity
Product groups ? The categories of similar products.

Creative Equipment

Variants finder

Selected variant:

Please indicate the following variant number when placing your order:

Make contact

This kaiser & kühne product enables:

Product downloads:

Technical data
Total height: 1,50 m
Area: 1,50 x 1,75 m
Minimum space: Ø 4,75 m (18 m²)

Posts
Posts made from stainless steel tubes Ø 120×3 mm covered by non-detachable protective stainless steel caps.

Attachment parts
– infill panel made from highly weather-resistant coloured HPL, framed by stainless steel tubes Ø 33,7×2 mm, with clock hands made from coloured HPL panels for manual time adjustment
– concave/convex mirror from high-polished stainless steel framed by HPL panels
– wheel of fortune made from HPL panel
– abacus: elements from Polyamide, Ø 80 mm
– tubular stainless steel chimes suspended from wire ropes, framed by stainless steel tubes Ø 33,7×2 mm. PVC drumstick included, suspended from the post by means of a chainless steel chain

Metal components: stainless steel
Thanks to a specific fastening adaptor, forces arising from the modular attachment parts are directly derived into the posts. Tamper-proof connections thanks to screws with security socket.

Foundations (on site)
6 pcs. 0,40 x 0,40 x 0,60 m
concrete amount: 0,58 m³

Approximate assembly values
2 mechanics 2 hour
(without creating foundations)

Appropriate for
users of all ages,
public playgrounds etc.,
manual activity

Creative Equipment

Classic

City

Aloha

Beach

Coral

Ice Palace

Jungle

Mermaid

Nature

Ocean

Pirate

Safari

Sky

Sun

Sunny Day

Sweden

Variants finder

Selected variant:

This kaiser & kühne product enables:

Product downloads:

For more information please contact us

Related products:

Clock 0-37203-500

Wheel of fortune 0-37202-700

Abacus 0-37200-500

Distorting mirror (concave) 0-37212-500
