Small Playground Equipment

Mini zoo 0-39005-000

Classic

Beach

Sun

Aloha

City

Coral

Ice Palace

Jungle

Mermaid

Nature

Ocean

Pirate

Safari

Sky

Sunny Day

Sweden

Technical specifications

Lifting device ? Appropriate hoisting equipment is necessary for assembling the playground equipment.

Total length ? The measurement indicating the length of the playground equipment.

2,70 m

Total width ? The measurement indicating the width of the playground equipment.

1,60 m

Total height ? The measurement indicating the height of the playground equipment.

1,50 m

Minimum space length ? The minimum required length for the space where the playground equipment will be placed.

5,70 m

Minimum space width ? The minimum required width for the space where the playground equipment will be placed.

4,60 m

Minimum space height ? The minimum required height for the space where the playground equipment will be placed.

1,50 m

Assembly time ? The time required by qualified individuals to assemble the product.

No specification

Heaviest single piece ? The weight of the heaviest component of the product. This information is crucial for transportation and assembly.

40,00 kg

(Total) Weight ? The total weight of the product. This information is essential for transportation and assembly.

210,00 kg

Free height of fall ? The maximum free fall height of the product, from which the required impact-absorbing surfaces, impact area size, and fall protection requirements can be derived according to (DIN) EN 1176-1:2017.

0,58 m

Platform heights

0,58 m

Foundations

5 pcs.

1,00 x 0,20 x 0,10 m
Volume: 0,02 m3

Age group ? The specific age group for which the product was developed.

1+
Number of users ? The number of individuals who can use the product simultaneously.

6
Area of use ? The different environments or situations in which the product can be used.

public playgrounds
Activities ? The various tasks or actions that can be performed with the product.

sliding, climbing, manual activity, social activity
Product groups ? The categories of similar products.

Small Playground Equipment

Variants finder

Selected variant:

Please indicate the following variant number when placing your order:

Make contact

Product downloads:

Technical data
Area: 1,60 x 2,70 m
Minimum space: 4,60 x 5,70 m (22 m²)
Total height: 1,50 m
Platform height: 0,58 m
Weight: 40 kg heaviest single component
210 kg as a whole

Attachment parts
– tubular stainless steel supports Ø 33,7 x 2 mm
– platform, climb up ramp and lateral panels from highly weather-resistant HPL panels, 13 mm
– steps from highly weather-resistant HPL panels, 25 mm
– stainless steel sliding surface of 3 mm thickness
– bear head from highly weather-resistant HPL panel, 13 mm
– bear body from highly weather-resistant HPL panel, 13 mm
– iceberg from highly weather-resistant HPL panel 13 mm
– bird beak from highly weather-resistant HPL panel 13 mm
– bird body from highly weather-resistant HPL panel 13 mm
– wing with slidable toy: made from highly weather-resistant HPL panel 13 mm, disc for slidable toy
– fish flapper from highly weather-resistant HPL panel 13 mm
– slidable toy balls: corrugated stainless steel tube Ø 38 x 2 mm with three Polypropylene ring-shaped balls
– Polycarbonate inspection glass
– eye and flower from highly weather-resistant HPL panels, 13 mm, attachment by means of POM bearing disc
– wing from highly weather-resistant HPL panel, 13 mm, with slidable stainless steel toy bricks
– slidable toy balls: corrugated stainless steel tube Ø 38 x 2 mm with three Polypropylene ring-shaped balls

At extra charge, for playing enhancement, there are various replaceable features on choice: cockpit, cog wheels, mirror, sliding puzzle, worm wheel or effect disc.

Please keep in mind, that the K&K Minizoo provides the attachment of one of the features. With placing the order, the type of feature must be defined.

Metal components: stainless steel

Foundations (on site)
usually, pounding is sufficient
(With loose ground: 5 pcs. 1,00 x 0,20 x 0,10 m = 0,02 m³)
concrete amount: 0,1 m³

Approximate assembly values
– delivery as a whole –

Free height of fall
0,58 m

Appropriate for
children from the age of 1 to 6 years,
public playgrounds etc.,
physical/social activity
